Basic Information |
||||||||||
|
Material name |
Wear -resistant alloy |
Card |
0WR05T |
|||||||
|
additive |
/ |
Exterior |
red |
|||||||
|
Characteristic |
|
|||||||||
|
Application field |
/ |
|||||||||
|
Product property data |
||||||||||
|
Test items |
Test Methods |
unit |
Test Data |
|||||||
|
Mechanical performance |
Tensile strength |
GB/T 1040-2006 |
MPa |
40.3 |
||||||
|
Elongation at Break |
% |
13.2 |
||||||||
|
Flexural Strength |
GB/T 9341-2008 |
MPa |
49.7 |
|||||||
|
Flexural Modulus |
MPa |
1513 |
||||||||
|
Izod impact strengt (V-notched) |
GB/T 1843-2008 |
kJ/m2 |
5.7 |
|||||||
|
Thermal performance |
Heat Deflection Temp（Tff1.8） |
GB/T 1634.2-2008 |
℃ |
/ |
||||||
|
other |
Density |
GB/T 1033-2008 |
g/cm3 |
1.25 |
||||||
|
Hardness |
GB/T 2411-2008/ |
HD |
/ |
|||||||
|
Melt Mass Flow Rate（270℃、2.16kg） |
GB/T 3682-2000 |
g/10min |
77.1 |
|||||||
|
Grinding |
GB/T 3960-2016 |
mg |
35.3 |
|||||||
|
Friction coefficient |
/ |
0.177 |
||||||||
|
Ash content |
GB/T 9345-2008 |
% |
/ |
|||||||
|
Mold shrinkage |
Machine |
GB/T 17037-2003 |
% |
/ |
||||||
|
Transverse |
% |
/ |
||||||||
|
Injection |
||||||||||
|
Dry temperature |
（120~140）℃ |
Dry time |
（2~4）h |
|||||||
|
Injection temperature |
（260~290）℃ |
Mold temperature |
/ |
|||||||
