Basic information

Material name

Flame retardant reinforced PET

Brand

PET0G30X2

additives

/

Appearance

true color

Features

Application fields

/

Product properties

Test items

Test methods

Units

Test data

Mechanical properties

Tensile strength

GB/T  1040-2006

MPa

126

Elongation at Break

%

2.9

Flexural Strength

GB/T  9341-2008

MPa

161

Flexural Modulus

MPa

6094

Izod impact strength (V-notched)

GB/T 1843-2008

kJ/m2

10.6

Thermal properties

Heat Deflection Temp（Tff1.8）

GB/T 1634.2-2008

℃

202

other

Density

GB/T 1033-2008

g/cm3

1.60

Melt Mass Flow Rate(270℃, 2.16kg)

GB/T 3682-2000

g/10min

twenty two

Glow wire temperature

GB/T 5169.10-2017

℃

850 (non-flammable)

Glow wire temperature

℃

960

Flame retardant grade

UL 94

/

V-0

Ash content

GB/T  9345-2008

%

29.0

Mold shrinkage

Machine

GB/T 17037-2003

%

0.2~0.4

Transverse

%

0.3~0.5

Injection molding process

Drying temperature

(130~150)℃

Drying time

(4~6)h

Injection temperature

(250~275)℃

 Mold temperature

/℃
